Ozone Production

0.9 g/h dissolved into water

  Dimensions

220 x 220 x 400 mm

  Weight

13 kg

  Feed Gas

Internal air supply

  Controls

Duty period and duty cycle can be determined by jumpers configuration

  Indicators

LED signals for power on/off and ozone generation

  Power supply

AC 220-240 V, 50/60 Hz, single phase

  Power Consumption

100 W (on-duty)

  Ozone Production

  Dimensions

400 × 250 × 600 mm

  Weight

38 kg

  Feed Gas

Air / under negative pressure suction

  Gas input pressure

1.0 kg/cm²

  Cooling method

Internal air cooled

  Power supply

AC 220-240 V, 50/60 Hz, single phase

  Power Consumption

230 W

PWOD-15 series

PWOD-15 (CI type)

PWOD-15 (CI type)

  Dimensions

600 x 600 x 1200 mm

600 x 600 x 1200 mm

  Ozone production

20 g/h

40 g/h

  Structure

  Corona discharge between the surface of two quartz tubes

  Feed gas

  Internal oxygen concentrator

  Cooling method

  Air-cooled

  Power supply

  AC 220-240 V, 50/60 Hz, single phase
